Dimensions
6 HP
Current Draw
? mA +12V
? mA -12V
? mA 5V
Price

Module is available as a DIY project only.

This Module is currently available.

MiniVCF

Unlisted Filter

Diode ladder filter with lowpass and bandpass

benjiaomodular's take on Moritz Klein’s diode ladder design with an added clipping section and a second filter so you can crank up the resonance while keeping the output at reasonable levels.

The module has a switch for lowpass or bandpass modes.

https://benjiaomodular.com/post/2022-03-11-mini-vcf/


submitted Apr 17th 2023, 12:24 by CoogLFish | last Change Apr 17th 2023, 12:25 by CoogLFish
