Rectifier

Combined halfwave and fullwave precision rectifier

It can be used as an AC to DC
converter, a distortion, a complex waveform
generator, a frequency doubler, a clock doubler
or even as part of an envelope follower.
Any bipolar signal provided signal (+/-10V)
inluding audio signals provided at the input will
be available on the three outputs in different
form.
Output 1 will provide the signals positive values
as they are and cut negative values to 0V.
Output 2 will do the same but with an inverted
signal, so originally positive values will be cut to
0V and negative values will be made positive.
Output 3 provides a fully recified version of the
input. Positive inputs will be sent as it is,
negative portions of the signal will be made
positive and also sent to the output.

https://github.com/mzuelch/CATs-Eurosynth/tree/main/Modules/Slim%20Line/Rectifier
