Dimensions
12 HP
40 mm deep
Current Draw
? mA +12V
? mA -12V
? mA 5V
Price

Available as an assembled Module and as a DIY project.

This Module is a prototype or in a concept phase.

Saw Core VCO

Unlisted Oscillator

The XTAL audio saw core VCO is a 12HP eurorack format oscillator

The XTAL audio saw core VCO is a 12HP eurorack format oscillator with the following features:

Simultaneous saw, pulse (with variable pulsewidth), triangle and sine outputs
Coarse and fine tuning control with a range of 0.03Hz to over 20kHz
1 v/oct input accurate over 7 octaves
Bipolar (attenuverting) exponential input
Unipolar linear FM input
Unipolar pulse width modulation input


submitted Dec 22nd 2019, 10:54 by richlanger
