Universal 8 jack I/O

universal module with 8 I/O jacks and pinheaders on the back (keystep pro, digitakt, ...)

usage with keystep pro has 4 separate instances:

     SEQ             SEQ
     ╔═╗             ╔═╗
     ║●║ S1 PITCH    ║●║ S3 PITCH
     ║●║ S1 VELO     ║●║ S3 VELO
     ║●║ S1 GATE     ║●║ S3 GATE
     ║●║ S1 GATE     ║●║ S3 GATE
     ║ ║             ║ ║
     ║●║ S2 PITCH    ║●║ S4 PITCH
     ║●║ S2 VELO     ║●║ S4 VELO
     ║●║ S2 GATE     ║●║ S4 GATE
     ║●║ S2 GATE     ║●║ S4 GATE
     ╚═╝             ╚═╝

     DRM        CLK
     ╔═╗        ╔═╗
     ║●║ D1     ║●║ CLOCK IN
     ║●║ D2     ║●║ RESET IN
     ║●║ D3     ║●║ CLOCK OUT
     ║●║ D4     ║●║ RESET OUT
     ║ ║        ║ ║
     ║●║ D5     ║●║ METRONOME Audio
     ║●║ D6     ║●║ Passive MULT 1
     ║●║ D7     ║●║ Passive MULT 2
     ║●║ D8     ║●║ Passive MULT 3
     ╚═╝        ╚═╝

usage with elektron digitakt:

     ╔═╗
     ║●║ Audio Out L
     ║●║ Audio Out R
     ║●║ Audio In L
     ║●║ Audio In R
     ║ ║
     ║●║ Headphones Out L
     ║●║ Headphones Out R
     ║ ║
     ║ ║
     ╚═╝
