CMOS 4046 core VCO.

  • Coarse, fine and initial freq tune.
  • LF (Low Frequency) button – on/off LFO mode, Bi-color led for rate indicate in LFO mode.
  • Sync input.
  • 1V/oct input.
  • Exponential and linear frequency modulation inputs with attenuator pots.
  • Manual pulse width (PW) and pulse-width modulation (PWM) control.
  • 6 wave outputs:
    Sin
    Triangle
    Saw (x2 base frequency)
    Zig (Triangle + saw)
    Square
    Pulse (PW and PWM control)
  • Diode protection on reversed power supply.
  • CNC milling front panel.
  • Handcrafted in Russia.
  • 30 mA +12V
  • 30 mA -12V
  • 0 mA 5V
  • 38 mm deep

This Module is currently available.

submitted Apr 29th 2018, 12:35 by White_Noise_Custom
