Dimensions
14 HP
35 mm deep
Current Draw
? mA +12V
? mA -12V
? mA 5V
Price

Module is available as a DIY project only.

This Module is currently available.

Specs are approved by the manufacturer

QUAD LFO in phase (quadrature) or multiple ratio or free mode.

QUAD LFO is a low frequency oscillator digital. It has three main functions:

  • In "phase" mode, a quadrature LFO. Each of the outputs is shifted by 90 ° with respect to the previous one. I.e. that the first output has no shift (0 °), the second is offset by 90 °, the third is offset by 180 ° and the final output is shifted by 270 °.

  • In "Lock" mode, all outputs are phase locked to the frequency of LFO1 with a fixed ratio between 1 and 8. That is to say that you can have such LFO1, LFO2 = 1xLFO1, LFO3 = 3xLFO1 and LFO4 = 8xLFO1.

  • In "Free X" LFO1 LFO acts as Master and LFO2 to 4 are free and independent of each other.

All this gives rhythm of VCO, VCF, Panoramic, etc. and thus create moods effects.

http://www.ozoe.fr/articles.php?lng=fr&pg=447&mnuid=316


Ø 5.00 (1 Votes) Average Rating
submitted Apr 16th 2018, 19:10 by Portamento | last Change Apr 22nd 2018, 16:51 by Portamento
