3 band pass filter - waveshaper

Vibrazum is very versatile with lots of voltage control inputs.

Feed 1 audio input into three separate voltage controlled band pass filters with voltage control resonance. Each channel is able to sweep in all the frequency spectrum.

The feedback is capable to resonate in the low frequencies. You can route every BP separately and also have a dedicated mix output with attenuation controls to shape your waveforms.

The filters are 2 pole 12dB/oct .

http://patchingpanda.com/vibrazum

  • 55 mA +12V
  • 53 mA -12V
  • ? mA 5V

Available as an assembled Module and as a DIY project.

This Module is currently available.

$231 Price in € submitted Jul 6th 2018, 09:21 by patchingpanda | last Change Jul 19th 2018, 01:26 by mt3
