VC LFO

Synthrotek is pleased to offer a complete line of eurorack synthesizer modules, power, cases and accessories in both complete units kits and panels & pcbs. We now offer a very complete analog modular monophonic voice with many accompanying utility modules. This new complete voice is the product of a collaboration with synth guru George Mattson, who now joins us in releasing our new MST (Mattson – Synthrotek) line of premium modules.

MST Voltage Controlled Low Frequency Oscillator is another tiny, useful module packed to the gills with features. Manual and CV control over rate with 3 discrete waveform outputs. A square wave can be used to clock modules such as our Noise, Sample & Hold module. Great for creating vibrato, tremolo or other classic modulation techniques. Great for frequency modulation, especially when connected to the MST analog VCO.

Features:

Voltage Control rate input with attenuator control

Manual rate control

Slew/Symmetry control

Positive and negative LED indicators

Square, triangle and sine wave outputs

Specifications:

Manual range: Approx 51 Second to Approx 102 Hz

Time with Max range, +5V CV: 1,450Hz

Time with Max range, -5V CV: 1 Hz

Time with Min range, +5V CV: 2 Hz

Time with Min range, -5V CV: 1.5 Hours

Skew range, all waveforms: 14% to 86%

http://www.synthrotek.com/products/mst-eurorack-modules/mst-vc-lfo/

  • 12 mA +12V
  • 13 mA -12V
  • 0 mA 5V
  • 48 mm deep
  • Ø 3.77 (13 Votes) Average Rating

Available as an assembled Module and as a DIY project.

No info about availability.

$125 Price in € submitted Feb 9th 2015, 17:42 by synthrotek | last Change Mar 2nd 2015, 22:39 by synthrotek
Specs are approved by the manufacturer
