RCD: Clock Divider with Reset and CV Rotation

Divide-by-1 to Divide-by-64, on 8 output jacks
CV Rotate jack to shift divide-by amount on all jacks
Reset trigger to reset/re-sync all jacks
Jumpers or optional break-out panel:
Select auto-reset
Select "Spread" mode
Select maximum divide-by amount (8/16/32/64)
Gate or Trigger outputs
Count-up or Count-down mode
ISP header connects to in-circuit programmer such as AVR ISP MKII for reprogramming code
Maximum input frequency 3kHz

Power consumption on +12V rail can be reduced from 33mA to 19mA by setting jumper to use 5V rail (which will draw 14mA on the 5V rail)

http://4mspedals.com/rcd.php

  • 33 mA +12V
  • 4 mA -12V
  • 0 mA 5V
  • 48 mm deep
  • Ø 4.39 (23 Votes) Average Rating

Module is available as a DIY project only.

This Module is currently available.

$179 submitted Oct 13th 2012, 00:15 by 4ms_Company | last Change Feb 8th, 18:31 by 4ms_Company
Specs are approved by the manufacturer
