Polyphonic MIDI to CV

Polyphonic MIDI to CV / Gate interface

Overview

  • DAC conversion on 16 bits (accuracy 1/600th of a half-tone).

  • Selection of the MIDI channel on each of the 4 voices.

  • 10 different types of CV on each voice: Note, Velocity, Release Velocity, Aftertouch Channel, Modulation or Control Change #2, #3, #4, #5 (in 7 or 14-bit).

  • 8 or 9 different Gate signal on each voice: Gate, Triggers of varying length, MIDI clock, Start/Stop, Reset.

  • Gate Outputs can be switched into Inputs and convert Analog Signal into MIDI Commands (%IDI Clocks, Start, Stop).

  • Mono mode with 4 independent channels or Polyphonic Modes 2-voice, 2 + 2-voice, 3-voice or 4-voice.

  • Drums Mode (up to 8 trigger output).

  • 6 different Scales : Tempered, Pythagoras, 5 TET (Tone Equal Temperament), 7 TET, 24 TET or Harry Partch.

  • Volt/Octave or Volt/Hertz output

  • Re-Trig notes can be activated or desactived.

  • Multipliers and divisors of the MIDI clock adjustable from x 12 to /4 on each channel.

  • Transposition on each channel of +/-12 half tones.

  • Transposition of channels 1, 2 and 3 directly by MIDI keyboard

  • Adjustment of the extent of the PitchWheel between 1/2 tone, 1 tone or 1 octave.

  • 8 memory banks for storing all the parameters with automatic backup of the last settings.

  • Selection of MMC ID to make sure that the module meets the good commands.

  • Cancellation of the offsets directly by the encoder, without screwdriver and without removal of the module

  • Tuning extremely precise and very simple by the encoder, without screwdriver and without removal of the module.

  • Display the incoming MIDI messages for diagnosing or troubleshooting (Real Time and 2 or 3 byte messages).

  • 13 editable parameters via Control Change.

  • Firmware update.

  • Works standalone or controllable by MIDI (directly or ACXBus).

http://acxsynth.com/midi2cv/m2cv.html

  • 50 mA +12V
  • 10 mA -12V
  • 0 mA 5V
  • 33 mm deep

This Module is currently available.
