2 – FlipFlops (Q and NOT Q outs for each) 2 – OR Gates 2 – AND Gates 1 – Buffer/Inverter

2 – FlipFlops (Q and NOT Q outs for each)

2 – OR Gates

2 – AND Gates

1 – Buffer/Inverter

This is a handy module. It’s nice to have a few ORs and ANDs around when you’re fiddling around with your clocks and percussives.

The Output from FlipFlop1 Q is normalled to the FlipFlop2 Input via the jack switch.

The NOT Q outs from the FlipFlops are fun to stagger your clock pulses or use as a Sub-Oscillator. The Inverter/Buffer can be sent to a Gate-Trigger converter and back to the OR to double your clock.

All the outs are Buffered.

http://animodule.bigcartel.com/product/logicogic

  • 55 mA +12V
  • ? mA -12V
  • ? mA 5V
  • 38 mm deep
