Phones

L-1

Dual headphones amplifier.

  • 8HP
  • two independent CMOY phones amps.
  • to minimize left-right crosstalk, both left channels are in one dual opamp, both right channels in another.
  • two input jacks for each channel are multiplies fro using a signal further.
  • I used OPA2604 but another dual opamps possible.
  • 6.3mm jacks are Rean NYS-2343.
  • dual potentiometres 50K log are available from Thonk.
  • ? mA +12V
  • ? mA -12V
  • 0 mA 5V
  • 33 mm deep
  • Ø 5.00 (2 Votes) Average Rating

Available as an assembled Module and as a DIY project.

This Module is currently available.

$165 Price in €
8 HP Utility
submitted Oct 20th 2016, 11:39 by L-1
