Drum-98

MFB

Stereo Drum Mixer-DISCONTINUED

MFB DRUM-98 Mixer

  • Stereo input for cascading
  • 5 x mono inputs
  • 5 x level and pan controls
  • Stereo output

The DRUM-98 module is an audio mixer, which was specially developed for the MFB drum modules, but also other manufacturers. When using multiple drum modules often results in a modular system, the problem is that not enough audio inputs to filter or VCA are present. If you want to, for example, edit an entire drum set with a filter, you need a separate mixer DRUM-98 as the module. DRUM-99 offers five adjustable inputs, which can be distributed each with an additional trim control in the panorama of the internal stereo signal path. Additionally features the module via a non-adjustable stereo input, with the help of which can cascade two or more DRUM-99 module. This input can also be for the module DRUM-06 (Tom Tom) are used, which also has a stereo output. Signals from the five mono inputs and stereo input are jointly connected to the stereo output, which can connect to two VCAs, filters or other sound processed modules can, but the can also be used as a direct output to a mixer or audio interface. The stereo output is technically designed so that you can add it with other stereo outputs.

  • 20 mA +12V
  • ? mA -12V
  • ? mA 5V
  • 22 mm deep
  • Ø 4.00 (3 Votes) Average Rating

This Module is discontinued.

$110 Price in €
12 HP DrumMixer
submitted Oct 13th 2012, 10:31 by elektrokick | last Change Nov 23rd 2017, 17:58 by loki3030

5 Users are observing this
