Four part probabilistic rhythm crossfader

Confundo Funkitus crossfades between two sets of four rhythms using probability. Three different probability curves can be selected to control the behavior of the crossfader. Per-part switch mutes are included with live performance in mind.

Connect up to four rhythm outputs to each of the two sets of inputs. Connect the outputs to modules that take triggers. Drums that take triggers are perhaps the easiest.

Toggle the Curve switch to the top position. If the crossfader is fully left, then only inputs on the left will create gates. If the crossfader is positioned in the middle, the Center light is illuminated the two rhythms are blended together: gates are generated any time either rhythm is played. If the crossfader is all the way to the right the gates generated come from the second (right-hand) set of inputs.

Between these extremes the produced rhythm is a combination of both sets of input weighted by the position of XFADE and which curve is selected.

Manual:
http://static1.squarespace.com/static/5572aedde4b0080836614a7b/t/5762c7196b8f5b9b1976a12f/1466091295903/CF_manual.pdf

Videos:
https://www.facebook.com/video.php?v=10153508150388394
https://www.instagram.com/p/1EFMRzSx8M/

http://www.noiseengineering.us/confundo-funkitus

  • 20 mA +12V
  • 11 mA -12V
  • 20 mA 5V
  • 21 mm deep
  • Ø 4.33 (3 Votes) Average Rating

This Module is currently available.

$222 submitted Dec 11th 2015, 13:33 by ParanormalPatroler | last Change May 26th, 16:31 by illiac

14 Users are observing this
