RK006

USBMIDI/Gate Hub / MIDI Merger,Filter,Clock Processor

MIDI MODE
Every output port on the RK-006 can be individually set to send out full MIDI or Gate pulses, making a lovely hybrid use of it’s 3.5mm TRS connectors: You can connect DIN5 MIDI Gear via the included TRS-A to DIN5 cables or just plug in a plain ‘stereo minijack audio cable’ (preferably shielded) to sync up modular gear or even ‘minijack-MIDI’ devices like the Korg Electribe or NTS-1 and such.

In MIDI mode you can apply MIDI Channel/Clock filtering and even clock modifiers (‘Multiclock’, allowing creative use of an abundance of sequencer gear which are available nowadays. Of course these ports can also power our RK-002 Smart MIDI processing cable as well.

GATE MODE
When you set a port to Gate mode the MIDI-Tempo-to-Gate multiclock is still available. This together with an assignable Run/Stop signal allows synchronisation of devices like older Sync24/DINSync units as the TR-808, TR-303 and TR-606 (just to name a few) but also newer ones like the Moog DFAM and Teenage Pocket Operators and anything inbetween; Directly from your MIDI device.

Gate signals can be triggered via a MIDI clock signal but also via MIDI Notes, adding the ability to bridge MIDI controller pads and modular gear.

MASTER CLOCK GENERATOR
The one-button on the RK-006 can be used to tap in a master clock or change presets on the RK-006 routing. You can also use it to switch from seemingly a MIDI merger/thru box to e.g. an independent dual-brain setup or one-big-master-gate-clocks-generator.

USB STANDALONE HOST
By using a simple (and included) OTG Adapter cable you can even connect plain 5V power and a USB hub to the RK-006 and host multiple USB-MIDI devices. The RK-006 will interconnect them and merge them together with the existing hardware ports. And because one USB-cable can route a whole lot more than just a MIDI-In or MIDI-Out we added extra filtering to specifically target these USB devices as well.

And while in the USB area: You can even plug in a USB Memory Stick with prepared MIDI files (also called ‘SMF’). You can export these files on a DAW like Bitwig, Fruityloops, Ableton or Reason and playback these prepared tracks on your DAWless system, ready to play or clock-slave on your standalone sequencer of choice and play along live with it.
