Dimensions
8 HP
26 mm deep
Current Draw
27 mA +12V
27 mA -12V
0 mA 5V
Price
$59 Price in €

Module is available as a DIY project only.

This Module is currently available.

Specs are approved by the manufacturer

Stereo Panning Mixer

ST MIXER is effectively a five channel stereo mixer with a really good sounding headphone amplifier built in. It is designed to be the final output module of a small portable system that you want to use with headphones or for recording via 1/8 inch stereo jack cable to a portable recorder.

The module consists of three mono channels with level and panning control and one stereo channel with level control and separate inputs for left and right. The stereo headphone output also has level control.

ST MIXER is perfect for a starter system with a couple of synth voices and a stereo effect. The headphone output can drive most headphones quite well and also doubles as a recording output to connect to for instance a Zoom recorder.

Available as DIY kit at Thonk!
https://www.thonk.co.uk/shop/sebsongs-stereo-mixer/

https://modular.sebsongs.com/2022/04/22/st-mixer/
