Dimensions
2 HP
40 mm deep
Current Draw
15 mA +12V
15 mA -12V
0 mA 5V
Price
$99 Price in €

This Module is currently available.

Specs are approved by the manufacturer

Quad Fixed Active High Pass Filters

HiPass is a quad fixed frequency high pass filter. The two first sections are 3-pole filters (-18dB/oct) cutting at 30Hz. This removes low frequencies generated by resonant filters, FM synthesis and DC offsets from your audio signals. Use them to process the main stereo output from your modular system and remove non-audible signals that limit your headroom! The bottom two sections are 3-pole filters cutting at 100Hz. They are designed to work exactly like the low-cut sections on your favourite mixing desk.

  • 4 fixed high pass filters (butterworth response curve)
  • Filters 1 and 2 : 3 poles – 30 Hz (DC remover – extreme low frequencies attenuator)
  • Filters 3 and 4 : 3 poles – 100 Hz (usual Lo Cut design on mixers)

https://www.shakmatmodular.com/products/hp.html


Ø 4.82 (38 Votes) Average Rating
submitted Apr 25th 2017, 11:35 by Bishop Dust | last Change Dec 1st 2022, 09:19 by Bishop Dust

54 Users are observing this
