Guitar Interface

Solid State Sound Research Labs SM020: Guitar Interface

This module connects guitar or another instrument with low level signal to modular system.

Input has adjustable high-gain pre-amplifier and two buffered sends.

Two separate returns are connected to outputs and can be attenuated from modular level to line level.

Also module has 2-channel 2-way multiplexer controlled by general footswitch. Module source sufficient current to drive LED placed on some footswitches such as one used with Mesa-Boogie Mini Rectifier.

Also, module can be used as AUX Send/Return bus or master output.

Complete technical data and device page is yet to be collected/created because this is prototype. All further data will be updated as soon as collected.

  • ? mA +12V
  • ? mA -12V
  • ? mA 5V
  • 69 mm deep
  • Ø 3.00 (1 Votes) Average Rating

Module is available as a DIY project only.

This Module is a prototype or in a concept phase.
