Multiphonic CV-to-MIDI Notes module

Most recent from the ADDAC MIDI Series, the 222 converts 4 CV inputs to four distinct polyphonic MIDI NOTES streams, with up to 6 note voices per input. This allows the user to send midi notes to external midi devices straight from your modular: just plug it into your classic synth or your favourite virtual instruments. Combined with the ADDAC221 you can fully control any external midi device.

Features:

The user can send midi notes to 9 different midi channels (3 BANKS with 3 MIDI CHANNELS each). So, any of the 4 cv inputs may independently send its data to one of these 9 midi channels.
• NOTE OFFs may be sent by pressing the NOTExOFF button or as soon as a trigger is received in the NOTE OFFx cv input.
• A trigger sent to the ALL NOTES OFF cv input (1-4) will remove all the notes at the respective MIDI INPUT.
• The OCTAVES switch (one per INPUT) transposes the notes from +1 to +2 octaves, a rate that can be extended by one more octave using the C1-C2 OFFSET knob.
• The ADJ.x trimmer calibrates the amount of voltage per octave to compensate a possible deviation in the CV IN received signal.
• USB MIDI received data will be routed to the MIDI OUT jack.
• In turn, midi data externally sent to the MIDI IN jack will be routed both to the MIDI OUT jack and the USB MIDI port.

http://www.addacsystem.com/product/addac200-series/addac222

  • 70 mA +12V
  • 30 mA -12V
  • 0 mA 5V
  • Ø 5.00 (3 Votes) Average Rating

This Module is currently available.

$403 submitted Mar 25th 2016, 09:14 by ParanormalPatroler | last Change Nov 5th 2016, 23:55 by ParanormalPatroler

9 Users are observing this
