Dimensions
14 HP
35 mm deep
Current Draw
78 mA +12V
70 mA -12V
0 mA 5V
Price
$339 Price in €

This Module is currently available.

Specs are approved by the manufacturer

Full analogue synth voice module for ultimate acid basslines

Full analogue synth voice module for ultimate acid basslines. It features AS3340 VCO with three waveforms, a filter inspired by Erica Synths Acidbox and unique features – transistor-based suboscillator and two BBDs that emulate VCO detune.

Features

Full analogue circuit
Accent
Suboscillator
BBD-based VCO detune emulation
Built in VCF and VCA decay envelope
LP/BP VCF
External VCO FM and VCF cutoff CV inputs

https://www.ericasynths.lv/shop/eurorack-modules/by-series/drum-series/bassline/


Ø 4.43 (21 Votes) Average Rating
submitted May 12th 2018, 07:34 by EricaSynths | last Change Oct 27th 2020, 13:40 by EricaSynths
