Dimensions
12 HP
36 mm deep
Current Draw
12 mA +12V
12 mA -12V
0 mA 5V
Price
$190 Price in €

This Module is currently available.

Specs are approved by the manufacturer

Mixer multifonction

NEW ! V2 available !
News: http://ph.neutre.free.fr/Telechargements/Manual%20ph%20Mixer++%20Add%20version%202.pdf

Mixer With :

  • 4 mono inputs including 1 mono or stereo (switching depending on the connection used, can be used return stereo effect)
  • 1 main level potentiometer (logarithmic curve)
  • 1 auxiliary mono output, with choice of output level via jumper on the back - new -
  • 1 stereo output on 3.5mm jack

Each channel comprises:
- 1 level potentiometer (log curve)
- 1 mute button (with bicolor led blue / red satut) to activate / desactivate the channel
- Auxiliary send pre or post level
- 1 pan potentiometer (with central detent)

  • Connection connector of a second Mixer ++ (connection cable supplied during a second purchase of Mixer ++). In this case, the output of the first Mixer is sent to the output of the 2nd Mixer. You thus have 8 channels, including two stereo as well as two independent auxiliary sendings, all "summed" on the stereo output of Mixer n ° 2 - new -

  • Parallel connection of the dedicated power supply to supply the optional "VUMETER" module. Also connected on the "Link to 2d Mix" connector. ", This module allows:
    - view the stereo output on a double 12 led's meter
    - separate the stereo mini jack output of the Mixer ++ into two mono L & R mini jack outputs (Note that this module can also be used without the Mixer, with d 'other mono or stereo audio modules) - new -

Review by inmodularwith.love (for audio signals use):

Also available in white panel :
alt text

The price includes: module and screw M3. Excluding shipping costs !!

Manufactured by Christian from ph modular.
Available as an assembled Module, no kit.
Tested and assembled by hand. All components are through, so all "ph" modules are repairable. Built to last ;-)

Manual : http://ph.neutre.free.fr/Telechargements/Manual%20ph%20Mixer++.pdf

To order, please contact me (phneutre56@gmail.com) the terms of payment, delivery times and shipping costs, will be detailed by return mail.
The payment will be in euros (€) and can be done by paypal. Delivery possible in the world, please contact me (phneutre56@gmail.com)
Shipping costs :
alt text
