Haha, looks pretty impressive! :-)

I didn't look at it for too long but it seems pretty light on mixers for that many VCOs?


Thanks so much for the flip option! I have been meaning to suggest it be added to the modules ever since I started using PedalGrid! ;-) I had to hunt down this thread so I could bestow my thanks. And yes, like ParanormalPatroler I now have to delete all my hidden upside down versions! lol

There is a slight bug with the spinner icon that I noticed in PedalGrid and it exists for the module spinner icon as well. It's no big deal but if I turn the Popover off, the spinner icon doesn't disappear along with the Info and Trash icons. A workaround is to refresh the browser which makes it disappear. Probably a tiny bit of code to change or a flag box to check? ;-)


I think that Synth Tech MU modules were in Other/Unknown because they never manufactured any MU modules. Any of the ones in ModularGrid are DIY hacks by individuals, at least that I can recall. I'm not saying to do it one way or another, I'm just saying. ;-)

Actually, is there a MG rule on that? I'm never sure if I should put a module that was DIY'd into a different format under the manufacturer of the "guts" or if it should be under Other/Unknown??


Hi again ;-)

That one user, balpirol, has uploaded sever images incorrectly. Like this one https://www.modulargrid.net/d/club-of-the-knobs-cp1c

Anyways, unfortunately ModularGrid doesn't support CP sized modules in the way that 1U modules are supported for Eurorack (hint hint? ;-) so there needs to be a blank section photoshopped in to take up the extra height so that it works correctly in a 5U row. Some people have used white blank space but I prefer black or "module color" dark grey.

I've made up several CP module images for MG and I started out by taking the image of one that already works in MG and then pasting the new module image over the top. Here's one of mine for reference, https://www.modulargrid.net/d/moon-modular-551cp


Hi,

The first two you listed "may" be duplicates, I didn't look at the listings very close, but the one on the FreeState FX is a different version.

The first two listed were 5U conversions they did from Braids eurorack modules by just replacing the panel and adding 1/4" jacks. So it's basically a eurorack module behind a 5u panel. It does have Moog standard panel coloring though.

The newest one on their site is a full redesign, where they took the Braids schematics and made up totally new printed circuit boards to accommodate the 5U format better. It's a gorgeous module and I G.A.S. over it just because of it's looks! ;-) This one has a deviation from Moog standard panel coloring since it's solid black with no white/silver vertical lines on the outer edges.


Hey all, I recently purchased a modular synth that has most of the modules in my rack - some patch suggestions would be nice :)
The rack is option no.2


Greetings

This module:

https://www.modulargrid.net/d/free-state-fx-macro-digital-oscillator

Appears to be a duplicate of this one:

https://www.modulargrid.net/d/free-state-fx-fsfx-101-macro-digital-oscillator-aka-braids

In addition, neither module image reflects the current image on FSFX's website:

https://freestatefx.com/collections/free-state-fx-modules/products/101

So I am unsure if first two module above are V1's with third module listed as V2. Or, is third module an entirely new product though it shares FSFX 101 module name with second module above. If second module is same as third module but simply needs revised image as displayed on FXFX site, I'd be happy to execute that.

Yay decluttering
Cheers


Greetings

Module images for Club of the Knobs CP8 (link below) is displaying too much white space in grid view which also appears on its module page when you click to enlarge panel image. I downloaded a new image from CotK's official site, properly cropped/converted/exported, then uploaded a new image but it's still displaying that extra white space. I tried this process twice different ways to no avail.

A bug perhaps?

https://www.modulargrid.net/d/club-of-the-knobs-cp8

CotK CP2 seems to be having the same white space issue. I didn't work on that image though.

Cheers


Great advice, thank you :)

I think this is a great way to get me started with Eurorack. I don't mind paying a bit more and not worrying about power / case balancing, etc.


Thread: Vocoder cab

A little (literally!) something...two Frap 42hp rows + vertical cab ends. I sorta felt that a vocoder should be a separate device so that it can go inline with most anything. Bottom row is Frap's new Fumana module. Top row...ok, the mic preamp/envelope follower on the left gets its audio patched to the VCA, while the gate from the envelope follower goes to the AHDSR...this enables some shaped noise gating, allows only the proper level signals from the mic to pass to the Fumana. Mono limiter to even out the inputted carrier input signal, EQ before the output to tweak timbre a little before the line-out. This way, the device can easily be patched into anything from a modular rig to line-level I/O signals for both the modulator (with its own mic/line in) and the carrier.

Not too shabby! Hopefully a few folks will get some ideas from this, because that Fumana module looks to be extremely cool, almost a competitor for an EMS 5000 with the fully routable analysis-to-synthesis patching. And at gazillion$ less!


Oh, yeah...it definitely needs some sort of stereo output module. Even just putting the Clouds (or something like it) last in the signal chain screams 'stereo output'. Get something with a ganged stereo level pot, though; I've been a bit enthralled lately with this one Olitronik output...1/4" balanced outs, metering, headphone preamp, and only 6 hp. Not spendy, either, and the ganged stereo control lets you easily maintain the spatialization coming out of the system. Happy Nerding also has a nifty and inexpensive output, this time with transformer-balanced outs, and having some nice iron in your audio path is always a help, as transformers tend to emphasize even harmonics, making signals processed that way a bit more 'euphonious'.


Yeah, that thing was a bitch to patch; the dope sheet for the patch for the ARP 2600 and Digisound tandemmed was 2 1/2 pages long. How it worked, though, was brilliant: the piece depended on a continuum of non-repeating, dynamically-shifting voltage curves that then got fed back out in all directions, with differing polarities and phases. Key to it was two things:

1) Eight attenuverters on the Digisound. These were the 'steering' controls. All of the various modulation signals fed into these and they functioned as a sort of 'network', in which incremental, small changes would knock the whole system out of, and back into, equilibrium. But that process had a lot of 'lag' built into it, so a change of one pot would perhaps take 10-20 seconds to make the resulting change sonically. That, plus the point that the modular system was fed into a long processor cascade, made any change done manually take a LONG time to finally reach a new stable state.

2) A shortwave receiver fed into three different audio frequency bands. This is the 'not under control' part. I used a fairly broad bandpass filter to rein in the sonics, and this was fed into the audio of the modular system at a very low level. Then out of that, two other 1/10th octave passband filters took 'slices' of that audio spectra and these were sent to the envelope followers on the ARP and Digisound, where their levels were converted into CVs and fed into the modulation 'network'. Since shortwave signals constantly fluctuate in phase, level, etc, there was no controlling what any of this would do at all. And, of course, it too is constantly dis-aligning the modulation curves.

The only other things on the track are an MS-20, which stays constant to provide a 'pivot sound' around which the rest of the sonic architecture moves, and a theremin which appears at points. When that happens, also, the keyboard controller gets used to 'dive' the modular's general pitch downward to 'window' the theremin solos. As for how I got the theremin to 'feed back' at that one solo's end...well, some things must remain a secret, heh, heh, heh...


This loses Temps Utile, Chance, Optomix, and O/A/x2 but moves the sequencing in-case via Meadowphysics and White Whale.


Thanks for the hint, I have corrected it.
Cheers ... and welcome!

Knut


Do you think I should get a uJack or something similar?


Original Clouds power consumption
120 mA +12V
10 mA -12V
0 mA 5V


Hi there

New registrant to this site and first post so forgive if incorrect location or protocol.

Synthesis Technology is available in Eurorack manufacturer dropdown list but not MU where they are currently attributed as "other/unknown" for their respective modules in that format. Synth Tech have been quite legit for a while, I think. ;-)

Cheers


I worked like a b*tch to get this one just right.

Any comments are welcome. Send me some love or offend me deeply, I'll take it any way it comes.


Fair request. I always go with the pricier option just to make sure, but that's just the way I think. Let's see what other people think.

All rights reserved, all wrongs reversed.

Nice, dreamy bells Synnic!

And Lugia, wow! This is a full on live set for an art museum och a similar venue. Creeping evolution, restrained, strong. Very impressive!


Thread: 2 of 2

PSU = +12V/1200mA, -12V/1200mA


Thread: 1 of 2

PSU = +12V/1200mA, -12V/1200mA


Thread: Change Log

Mucho brilliant, gang...thanks! Should cut down on dupe modules. I saw the rotator on the stompbox category and had been hoping it might get adapted for everything else.

Just another little thing that makes MG the 'gold standard' reference for modular...


Hey, it works, that's awesome. Thank you much.



Now to remove all the duplicates :D :D :D
This is great!

All rights reserved, all wrongs reversed.

Thread: Change Log

Flip Modules

There are people who like their modules mounted upside down for ergonomic reasons.
With the new flip function you can rotate module by 180°. There is also the keyboard shortcut f available.


Is there a way to rotate/flip individual modules, such as a Batumi where the CV patch points are on top rather than on bottom?
-- RunnyKine

We've been discussing adding the option to flip a panel for while.
-- ParanormalPatroler

The future is now! I have added a 180° flip function. There is also the keyboard shortcut f available. I hope I did not break anything ... Thanks for reminding me, guys!


Thank you @nuuttipukki! Recommended.


One idea would be to actually Edit the available module (if possible) and change the panel to the reverse. Users can scroll through available panels via the Panel option. Both normal and flip versions would be available on the same module.

The problem with that is a) not everyone knows it b) most people would get their panels flipped all of a sudden.

:)

All rights reserved, all wrongs reversed.

Ok, thanks.


We've been discussing adding the option to flip a panel for while. It could/should be implemented in some in the future. In the meantime, if the module is not already available as upside-down you can add it yourself, but make sure to tag it as Unlisted. It's a bit of a pain to get duplicate modules just because someone wanted the panel flipped (my personal opinion anyhow). I have a few that I've uploaded myself (it's a fair request) but I tag them as Unlisted to avoid duplicates for others. :)

All rights reserved, all wrongs reversed.

Is there a way to rotate/flip individual modules, such as a Batumi where the CV patch points are on top rather than on bottom?

I realize the writing and controls would be upside down, but people flip them in real life just the same.

Surely this has been asked and discussed before, did I miss the feature, or has it be omitted on purpose, or what?

Thanks. Amazingly useful site...


Hey, gang...this is for those of you submitting module data on items that come in both kit and prebuilt versions. If you could, please put the worst-case price on module listings. This will almost always be the prebuild price, not the kit, and the reason I'm making a note here about it is that I just got done reworking the Elby stuff, and a lot of the prices there were on kit versions, and I (like quite a few around here, I'll guess) tend to plan things as prebuilt. So when the rack of Euroserge stuff I had shot from $15k up to $24k...well, that's quite an inflation rate!

I think most people, when they get the bill on things, would like to see it was lower than they'd thought as opposed to "what do you mean I owe you another 9 grand!?". So, yeah...while I know there's a big DIY presence on here, I think everyone will agree that you're going to want the NICE surprise as opposed to the HOLY CRAP!! surprise. So, yeah...let's see the prebuilt pricing when there's a difference, please? Vielen dank!


Pretty excellent! You might reconsider the 1/4" outputs, though, and drop a mixer (possibly w/ VCAs) in instead. That way, you can mix/attenuate up in the RackBrute and send the resulting audio back down to the MB2s's audio in and final-mix in that box. Pairing the Drips w/ the DFAM is a brilliant move, also, but also pushes that need for a mixer.

I did a test layout along similar lines, myself...have a look at the DAMN YOU, ARTURIA thread under 'Racks' from a few weeks back. The sort of patchables we're starting to see now really encourages this sort of thing, and I think it was really prescient of Arturia to come up with a unitized design that pairs the MB2/2s with an attached Euro cab. Granted, that build is more extensive, but it's interesting.


Something strange happened. I can't seem to read the post and the rack is wrong. Should be ModularGrid Rack


I'd pair this with the Arturia MiniBrute 2S.

I've zero experience with Eurorack. The Arturia kit gives me an easy in so I don't have to worry about cases / power etc. I love the DFAM.

Does this look like a valid fun system?? This is primarily for beat making.

I want to be able to control it (midi) and record the output (audio) so I added modules for that.

Thanks!


audio : https://mengqi.bandcamp.com/track/lights-are-from-a-window

mengqimusic.com

That was very helpful, thank you.


Sounds right...just keep in mind that, musically, you're probably best putting the modular cab together in a way that it doesn't sound at all like the 0-Coasts so that you can get some contrast. It's sort of like orchestration: sure, you have five different string parts to an orchestra, but then you'll want the wind colors to contrast against the monolithic string timbres. At the same time, tho, those strings need to interconnect with the winds...and likewise, tandemming control patching between the 0-Coasts and the modular cab is a great idea.

Yeah, I might've had some texts shoved up my ass during my undergrad conservatory-type training that I thought were sort of pointless (Piston's 'Harmony', f'rinstance), but Rimsky-Korsakov's text on orchestration wasn't one of those. I've found ideas from that orchestration textbook useful in multitrack and live mixing, studio equipping, arranging timbral structures in electronic media, and so on. Just proves that old adage about everything old being new again...(https://www.amazon.com/Principles-Orchestration-Nikolay-Rimsky-Korsakov/dp/1492248061 )


Answer #1: yes. Also, if you start speccing your own power supplies, you can find plenty of supplies that output lots more current than many OEM Eurorack supplies. This is especially useful when dealing with a large build. Or, alternately, you can go with a prebuilt larger case that has beefy amperage ratings...they've gotten a little more common, with the advent of cabs such as the larger Pittsburgh units (they're actually Monorocket designs, if I remember right) or the new (and cheap!) Arturia RackBrutes. Finding +12 only units might be a bit of a pain; you're better working out staying under the uZeus's requirements in its cab unless you toss it out and get something with more 'beef', like a 4ms Row Power 40 or a Koma Strom+.

Answer #2. I wouldn't try it. The issue there is that the -12 circuitry is going to expect to see a 'neutral' on its ground plane, not +12. This would be the only actual solution, as you would have a lot of trouble repolarizing that bus due to that issue. One module might be fine with it, but a couple of others might smoke. Again, the real solution (that avoids even the hint of a catastrophic possibility) is to either stay within the uZeus's limits or jettison it for a beefier supply.

That being said, though...the -12 rail on the Tiptop isn't as overtaxed as you might think. I like to spec current draws at 2/3rds of the rated maximum, which for .5A comes out to 333 mA, which is about where you are at present. So the ultimate answer here might be 'do nothing, it's just fine that way'.

One last thing: if you're planning to spec out your own power distro design for a new case, two things have to be kept in mind:

1) While linear supplies offer very quiet, no-ripple DC, they're spendy and weigh quite a bit. So this means you'd likely be using switching supplies...but in that case, you have to be concerned about noise on your DC rails. In bog-simple analog modules, this might not be a problem, but if we're talking about analog-controlled digital, the noise factor could creep in due to the switching noise interfering with the DSP clocking and such. These things can also radiate noise, so the potential for power supply garbage getting into other subsystems (think audio lines and devices here) goes up. Be VERY careful about noise factors on switchers.

2) You're always safer by using filtered busboards. Even with the quietest linear DC supplies, some modules can still send crud back down their own DC feeds which get back into the rails and spread out that way to cause all sorts of annoyance. Filtering reduces this problem, and can also be useful to reduce switching supply crud. If that's not enough, there's also various methods of isolating the DC supplies via filtering, noise chokes, etc that can get more garbage off the rails. The optimal thing you're looking for here is to drop the noise across your audio to as low a figure as is possible, as that will be the most obvious path for it to get heard...but just as much, reducing noise also helps with module stability, especially when tuning stability is critical. I would suggest putting a 'scope on your DC rail feeds during any such build to look for ripple (very bad) or switching noise to see what courses of action, if any, you might take.


Actually, both ideas there work...I keep forgetting that Quadnic module, and I ought not to. It's definitely a different character than the analog-source Doepfer, comes in considerably cheaper (by $200!) and saves 6 hp of space. Downside, though, is that you lose individual modulation and sync patchpoints. The other similar solution that seems to be viable gets more pricey, though: a pair of Klavis Twin Waves. $498 for two, but they fit in 16 hp and have way more features than either the Quadnic or the Doepfer combined. It's almost Braids-ish, given the algorithm feature set. If the price weren't a barrier, honestly, I'd go in that direction. As for the Pico DSP, yeah, that could work as well, but if you're going to use it for that insert trick make sure it can do a decent job on a mono output. Of course, that module also need not be a effect processor; you could do some twisted things with waveshaping in that Chronoblob feedback loop, so that every delay iteration keeps getting more distorted and bent out of shape. A ring modulator would be neat as well, but you'd need a carrier source...even so, consider a delay in which the iterations get more and more clangorous. Lots of possibilities exist...

As for the MAX situation...there might be a solution in MAX that can emulate the additional Monome modules. MAX is so open-ended that if you're deep into it, there'll almost certainly be a way around any hardware limit. Or, explore some of the Expert Sleepers stuff to get the MAX patterns over USB (or even ADAT optical) to their hardware, piping the MAX patterns through Silent Way. At the very least, ES's stuff saves space and is equally open-ended as Monome's modules.


Hey all! I've finally assembled enough components to have a functioning rack with some good possibilities. I'm pretty much out of space in my first case. When I look at the calculated power consumption, I see this:

633 mA +12V | 346 mA -12V | 0 mA 5V

I'm using the uZeus power supply from Tiptop Audio, meaning I have at my disposal:

  • 2000ma at +12v
  • 500ma at -12v
  • 170ma at +5v

It seems like I'm quickly approaching the end of the -12v space. However, it looks like I still have a good deal of +12v and all of my +5v.

Now, please forgive my ignorance of electrical engineering - I have two questions:

  • If I were to buy another case without a power supply, can I selectively look for modules that only use +12V and +5V?
  • Is it possible to convert modules from -12v to +12v? (IE with an adapter?)

What do you think of the Quadnic in place of the Doepfer Quad VCO?

Also, what about the Erica Synths Pico DSP in place of the verb module?

Some people are also recommending I ditch the Monome White Whale and Meadow Physics b/c the Ansible has similar functionality, and it would free some space for more mixers, but my thought was running multiple concurrent patterns on the 4 monome modules. I currently run 6 patterns or more simultaneously in MaxMSP...

Thanks!


Thanks , lots of food for thought here!

I am going to dig into this and see what I like!


First small rack? Don't you mean first small BIZZARO rack? MUA-HAH-HAH-HAAAAA!

OK, let's make it bizzaro...

Keep the MATHS where it is. I assume you're using a self-contained 84 hp rack, such as a Doepfer A-100LC3; this will have internal power with a built-in DC 'brick' input. If that's the case, this build should work.

Next, add the Batumi and the Poti expander. You will likely want the extra flexibility. So...ok, this gives us the Batumi for modulation, and the MATHS can do a lot of the envelop-ish and slewing behavior.

Then...BIZZARO oscillator! The Harvestman's Hertz Donut mk II should be perfect to compliment the analog oscillators in the two 0-Coasts. This is a very strange but extremely capable dual digital oscillator with internal modulation paths and TZFM capability. The spacing on this also takes care of the odd offset from the Poti, bringing us back into even hp turf. So, what better to go with a BIZZARO oscillator than...yeah, you guessed it...

BIZZARO filter! This thing is brilliant for strange timbres and filter modulations: the Limaflo Motomouth (https://www.modulargrid.net/e/other-unknown-limaflo-motomouth). It's a multiband formant filter based not on typical cutoff and resonance models, but emulating vocal vowel formants and morphing. Put together with the Hertz Donut, you then get into this very strange, alien voice-but-not-voice territory.

Next, not BIZZARO...just a dual VCA from Doepfer, their A-132-3. These VCAs can be switched between linear and exponential behavior, so while one can handle audio dynamics (f'rinstance), the other can deal with controlling a modulation signal's levels being fed...well, most anywhere. Since this is sort of a monosynth (ok, yes, a BIZZARO monosynth), there's really only a single signal path for audio at this point, so having two VCAs like this is pretty optimal.

Next...more BIZZARO! Right next to each other, a Synthrotek VERB, which is a CVable mono reverb, and a Feedback 106 Chorus, which not only modulates the timbre, but spreads the mono VERB signal into stereo in a few different, manually-controllable ways, so that its output goes right to a Malekko Output which gives you a ganged stereo level and steps your signal down to regular ol' line level. Not BIZZARO line level, mind you...just the usual.

Fills all 84 hp neatly. And there's way more than ample room for exploration there...plus it's going to sound NOTHING like the 0-Coasts or, really, most any other monosynth, because this is a...yep...BIZZARO monosynth! Also, you can patch the 0-Coasts in and out of this really nicely in oodles of ways. The SQ-1 could, say, sequence only one half of the Hertz Donut, leaving the other oscillator fixed to create lots of Conrad Schnitzler-esque clangers, or...well, you get the BIZZARO idea here, I presume.

(Last damn time I watch that 'Sealab 2021' episode before trying to get something done! And NO, not something BIZZARO done!)


Hello everyone.
ModularGrid Rack

I am putting together my first (small) rack.

I will be using this with two 0-Coasts , a multicassa and an SQ-1.

I know I want a Maths and pretty sure I want the Batumi.

I am mostly interested in dark, drones, ambient and weirdness.

I've been loving my 0-Coasts but really want to explore more sounds!

Any & all suggestions & opinions welcomed!

Thanks!


Great advice, cheers! I am limited by budget at the moment, so this is more a foundation rack with the basics from which I can expand on in time, but this is really good feedback so I'll have a rethink.


Just got a module from @isle. Very smooth transaction and no problems at all.


To get your image to refresh, try this: go into View Screenshot and if you see something that wasn't what you selected, then refresh that window. Should clear that up.

Anyway...had at it a bit myself. Started with flipping the case, and then...well, have a look:

ModularGrid Rack

There's definitely some changes. The Quad VCO is paired with the Quad VCA, for starters. This lets you do a lot of CVable mixing of the VCOs, creating morphing-like structures, or really most anything. Mangroves next, then a CVable wavefolder, which not only lets you morph the formants, but also the timbral quality of the Mangroves. Two attenuators to control their levels going into the Sisters VCF...and this is key, because I looked at that filter and noted that it has this extra input, CENTRE, that allows a 'lead' part to get 3db out front and be timbrally altered against the other sounds coming in via the ALL, LO, or HI inputs. The dual attenuator lets you have more control over that lead/back balance.

Then there's a Doepfer A-106-1 filter. This is actually a filter pair, based on the Korg MS-20's Sallen-Key pair, but with the sick and twisted addition of an insert in its resonance path. Hence the stuff below: a Chronoblob delay and a VERB digital reverb. Now, what came to my diseased mind was this: put the Chronoblob into the A-106-1's insert. Now, the Chronoblob ALSO has an insert...this time, in the feedback path. So the CVable VERB goes into THAT...allowing clocked delay pulsations with the added strangeness of constantly-shifting 'room' depths, with all of this being constantly inline to alter the dual filter's behavior. Tres ambient! Of course, there's plenty of other ways to (ab)use those, too...

ER-301 is above the other set of VCAs, next to a little 4-in stereo mixer, which is next to the Clouds. This puts the Clouds in place to easily process/mangle incoming audio OR the synth's sounds themselves, and all of this can be sent up and thru the ER-301 for more processing mayhem. The I/O is right below in the tile row, also, so the right end of the build can do a lot of 'spiderwebbing' amongst all of these for pretty infinite possibilities of subpatching for sonic alteration.

Bottom (now) tile row. Added the uMIDI 1U because the Intellijel cab's USB port (on the backplane) directly links to that for MIDI-over-USB use. Above this are your Monome modules, and this puts all incoming control signals at the lower left...nice and cohesive. Modulation/clocking is next to this, with the corresponding tile below the Tides and MATHS so everything's all in place to work as a modulation subpatch team. The row went to the bottom, also, to get your external cable runs below and away from your patchwork to avoid confusion. It also puts the tile controls close at hand to your controller for fast 'nuance' adjustment.

Sole flaw here is that I wound up being forced to drop the multiple. However, you might find that using stackable cables and/or inline mult modules work even better in this small a rig.

Downside of all of this: $5,668, modules alone. Definitely above the $2500 line, but it gives you something of a point to aim for, money-wise, even if the module compliment might change. But this isn't a bad aiming point, IMHO...definitely feels like an ambient 'instrument'.

Whatcha think?
